Patriot · Electric Fence Energizer · Model P30
Patriot P30 Dual-Purpose Electric Fence Energizer — 3 J
Patriot P30 is a low-impedance, dual-purpose energizer with 3 J output and 4.6 J stored energy. It supports battery, mains-adaptor and solar-powered installations. Power: AC Adapter · 12 V Battery · Solar Compatible.
Pang retail price
RM1,250.00
- Maximum Output Energy
- 3 Joule
- Manufacturer Rated Fence Length
- 104.61 km
- Power Source
- AC Mains Via Included Adapter, 12 V DC Battery, Solar Compatible With 12 V Battery And Charge Controller
From Patriot · Explore Electric Fence Energizer systems
Pang Electronics maintains the master product information and retail price. Stock and checkout are handled by PE Mall when a Webstore listing is available.
Product overview
Built for the job in front of you.
Product Description
Patriot P30 is a low-impedance, dual-purpose energizer with 3 J output and 4.6 J stored energy. It supports battery, mains-adaptor and solar-powered installations. Maximum coverage: up to 65 miles (approximately 104.61 km) and 260 acres. Actual coverage depends on fence and farm conditions. Features include an LED indicator, robust housing and straightforward mounting. Power adaptor and battery leads are included; solar operation requires a compatible battery and panel setup. Supports 12 V battery operation. Check the supplied adaptor’s input rating before connecting to mains power. Three-year manufacturer warranty including lightning, subject to applicable local terms. Output voltage (maximum/no-load): 11 kV. At 500 ohms: 6400 V. Typical current at 12 V: 0.3 A. Minimum earth rods: 3. Power Source: AC Mains Via Included Adapter · 12 V DC Battery · Solar Compatible With 12 V Battery And Charge Controller.
Why it helps
- Choose battery, mains-adaptor or solar operation to suit the fence location.
- Check operation at a glance with the LED indicator.
- Set up conveniently using the included adaptor and battery leads.
- Use the practical mounting arrangement to position the energizer where needed.
Technical highlights
- 3 J maximum output energy
- 4.6 J stored energy
- 11 kV maximum/no-load output voltage
- 6400 V output at 500 ohms
- Low-impedance design
- LED indicator
- Solar compatible
- Power: AC Adapter · 12 V Battery · Solar Compatible
Product Specifications
Energy & Output
- Stored Energy
- 4.6 Joule
- Maximum Output Energy
- 3 Joule
- Output Voltage Presets
- 11kV
- Output Voltage @ 500 Ω
- 6400 V
Fence Capacity
- Manufacturer Rated Fence Length
- 104.61 km
Power
- Power Source
- AC Mains Via Included Adapter, 12 V DC Battery, Solar Compatible With 12 V Battery And Charge Controller
- Current Consumption
- 0.3 A
- Recommended Battery Voltage
- 12 V
What's in the box
Package contents
- 1 ×Patriot P30 energizer
- 1 ×Power adaptor (confirm local input rating)
- 1 ×Battery lead set
- 1 ×AC Power Adapter
