Pro Fence · Solar & Battery
ProFence 30 A PWM Solar Charge Controller
ProFence 30 A PWM solar charge controller for automatic 12/24 V battery systems.
Pang retail price
RM60.00
From Pro Fence · Explore Solar & Battery systems
Pang Electronics maintains the master product information and retail price. Stock and checkout are handled by PE Mall when a Webstore listing is available.
Product overview
Built for the job in front of you.
Product Description
ProFence 30 A PWM solar charge controller for solar charging and compatible battery systems. This ProFence controller is OEM-supplied from the SUOER ST-S1230 platform and supports 12 V or 24 V systems with selectable lead-acid, lithium-ion or LiFePO4 battery settings. Specifications - Rated current: 30 A - System voltage: 12 V / 24 V - Maximum input voltage: below 50 V - Maximum solar input: 300 W at 12 V / 300 W at 24 V panel configurations shown in the manual - USB output: 5 V / 2 A - Standby current: below 10 mA - Working temperature: −35 °C to +60 °C - External battery: 12 V or 24 V, 100–150 Ah range shown Connect the battery before the solar panel and load. Match the controller setting to the battery type and confirm polarity before use.
Why it helps
- Supports automatic 12 V or 24 V solar systems.
- 30 A PWM charging control for compatible batteries.
- Selectable lead-acid, lithium-ion and LiFePO4 settings.
- LCD display and USB 5 V / 2 A output.
Technical highlights
- 30 A rated current
- 12/24 V system support
- PWM solar charging
- Maximum input below 50 V
- USB output 5 V / 2 A
- −35 °C to +60 °C operation
Where it fits
- Solar electric-fence systems
- Off-grid farm power
- 12 V and 24 V battery charging
