Pang Electronics · Electronic & Electrical · Model APT6S
ANLY APT-6S Weekly Programmable Timer – DC 12–48 V
ANLY APT-6S weekly programmable timer with DC 12–48 V supply, 8 daily settings, 15 weekly combinations and lithium battery backup.
Pang retail price
RM189.00
Explore Electronic & Electrical systems
Pang Electronics maintains the master product information and retail price. Stock and checkout are handled by PE Mall when a Webstore listing is available.
Product overview
Built for the job in front of you.
Product Description
ANLY APT-6S weekly programmable timer for automatic control of compatible DC equipment. It can operate as a weekly or 24-hour timer, with multiple daily settings and lithium battery backup for power interruptions. Specifications - Model: APT-6S - Supply: 12–48 V DC - Frequency: 50/60 Hz where applicable - Daily settings: 8 - Weekly combinations: 15 - Contact rating: 240 V AC, 7 A normally open / 5 A normally closed resistive load - Power-failure memory: up to 1 year via built-in lithium battery - Power consumption: approximately 3.3 VA - Operating temperature: −10 °C to +50 °C - Humidity: maximum 85% RH, non-condensing - Weight: approximately 150 g Confirm the DC supply and connected load are within the timer ratings before installation.
Why it helps
- Supports weekly and 24-hour scheduling.
- Provides 8 daily timing settings.
- Offers 15 weekly programme combinations.
- Lithium backup retains programmes during power interruptions.
Technical highlights
- APT-6S model
- 12–48 V DC supply
- 8 daily settings
- 15 weekly combinations
- 240 V AC relay output
- Up to 1-year programme backup
Where it fits
- 12 V and 24 V electric-fence equipment
- DC lighting and control systems
- Ventilation and agricultural equipment
