LC-308S USB Music Bell – MP3 Audio
LC-308S USB music bell that plays MP3 files from a USB flash drive, with adjustable volume and timer connection.
Pang retail price
RM178.00
Explore Electronic & Electrical systems
Pang Electronics maintains the master product information and retail price. Stock and checkout are handled by PE Mall when a Webstore listing is available.
Product overview
Built for the job in front of you.
Product Description
The LC-308S plays MP3 audio files stored on a USB flash drive. A compatible programmable timer can control when the bell receives power, while the LC-308S controls music selection and playback. Specifications - Model: LC-308S - Audio format: MP3 - Storage: USB flash drive - Rated power: up to 10 W - Volume: adjustable 0–92 dB - Frequency response: 125 Hz–13 kHz - Approximate size: 260 × 180 × 120 mm - Power supply: check the voltage on the supplied product label Installation and use - Copy MP3 files directly to the USB drive root directory and insert the drive. - Select the starting track with Music Select and adjust the volume gradually. - Connect the bell through a compatible programmable timer if scheduled operation is required. - Install indoors in a dry, secure position and remove power before wiring. - Do not remove the USB drive while audio is playing.
Why it helps
- Plays custom MP3 audio from a USB flash drive.
- Volume can be adjusted for the installation.
- Supports one fixed sound or sequential track playback.
- Can be connected to a programmable timer for scheduled alerts.
Technical highlights
- LC-308S model
- MP3 playback
- USB flash-drive storage
- Adjustable 0–92 dB volume
- Up to 10 W rated power
- 125 Hz–13 kHz frequency response
Where it fits
- School bell systems
- Factory and workshop shift alerts
- Office and institutional announcements
