MAXSON · Electric Fence Energizer
Maxson M20 2.0 J Electric Fence Energizer
Maxson M20 12 V energizer with 2.0 J maximum output energy and 10 km maximum working distance. Power: AC Adapter · 12 V Battery · Solar Compatible.
Pang retail price
RM600.00
- Maximum Output Energy
- 2 Joule
- Pang Recommended Fence Length
- 2 km
- Power Source
- AC Mains Via Included Adapter, 12 V DC Battery, Solar Compatible With 12 V Battery And Charge Controller
From MAXSON · Explore Electric Fence Energizer systems
Pang Electronics maintains the master product information and retail price. Stock and checkout are handled by PE Mall when a Webstore listing is available.
Product overview
Built for the job in front of you.
Product Description
A Maxson electric-fence energizer for livestock, pasture and farm boundary fencing. Specifications - Output voltage: 12 kV - Load voltage at 500 Ω: 5.9 kV - Input: DC 12 V, 220 mA - Stored energy: 2.8 J - Maximum output energy: 2.0 J - Maximum working distance: 10 km - Water protection: IPX4 - Physical dimensions: 218 × 153 × 69 mm - Gross weight: 1.76 kg Use and installation - Install in a dry, protected location. - Connect the fence and earth system according to the supplied wiring instructions. - Use a suitable 12 V battery and keep high-voltage conductors clear of buildings, vegetation and other wiring. Power Source: AC Mains Via Included Adapter · 12 V DC Battery · Solar Compatible With 12 V Battery And Charge Controller.
Why it helps
- 12 V operation suits battery-powered fence systems.
- IPX4 protection supports suitable outdoor installations.
- Model range offers options for different fence sizes.
Technical highlights
- Maximum output energy 2.0 J
- Stored energy 2.8 J
- Output voltage 13.3 kV
- Maximum working distance 10 km
- DC 12 V input
- IPX4 water protection
- Power: AC Adapter · 12 V Battery · Solar Compatible
Where it fits
- Livestock fencing
- Pasture boundaries
- Farm and crop-protection fencing
Product Specifications
Energy & Output
- Stored Energy
- 2.8 Joule
- Maximum Output Energy
- 2 Joule
- Output Voltage Presets
- 12kV
- Pulse Interval
- 1.5
Fence Capacity
- Pang Recommended Fence Length
- 2 km
- Manufacturer Rated Fence Length
- 10 km
- Recommended Area (3-wire fence)
- 5 acres
- Maximum Wire Roll
- 4 500 m/roll
Power
- Power Source
- AC Mains Via Included Adapter, 12 V DC Battery, Solar Compatible With 12 V Battery And Charge Controller
- Current Consumption
- 0.28 A
- Input Voltage
- 12
- Power Consumption
- 3.36 W
- Recommended Battery Voltage
- 12 V
- Minimum Battery Capacity
- 35 Ah
- Minimum Solar Panel
- 40 W
Monitoring & Display
- Pulse Indicator
- Yes
- Battery Indicator
- Yes
Application
- Suitable Animals
- Monkey, Wild Boar, Goat, Sheep, Cow, Deer
Physical
- Weather Protection
- IPX4
What's in the box
Package contents
- 1 ×Maxson M20 2.0 J Electric Fence Energizer
- 1 ×AC Power Adapter
- 1 ×DC Power Cable
