TVOE · Electric Fence Energizer
Tvoe TV20 2.4 J Electric Fence Energizer
2.4 J output-energy Tvoe energizer for up to 20 km stated wire length. Power: AC Adapter · 12 V Battery · Solar Compatible.
Pang retail price
RM640.00
From TVOE · Explore Electric Fence Energizer systems
Pang Electronics maintains the master product information and retail price. Stock and checkout are handled by PE Mall when a Webstore listing is available.
Product overview
Built for the job in front of you.
Product Description
A Tvoe electric-fence energizer for livestock, pasture and farm boundary fencing. Specifications - Stored energy: 3.6 J - Output energy: 2.4 J - Pulse frequency: 1.5 / 2.5 s - Output voltage: 9 kV / 12 kV - Maximum output current: 200 mA - Load output voltage at 500 Ω: 6.0 kV - Maximum wire length: 20 km - Consumption: 3.4 W - Power supply: 12 V or 100–240 VAC adapter, 50 Hz Use and installation - Install in a dry, protected location. - Connect the fence and earth system according to the supplied wiring instructions. - Use a suitable 12 V battery, adapter or solar charging arrangement. - Keep high-voltage conductors clear of buildings, vegetation and other wiring. Power Source: AC Mains Via Included Adapter · 12 V DC Battery · Solar Compatible With 12 V Battery And Charge Controller.
Why it helps
- Suitable output for medium farm and livestock fence layouts.
- 12 V and adapter power options support flexible installations.
- LED indicators assist with operation checks.
Technical highlights
- Output energy 2.4 J
- Stored energy 3.6 J
- Output voltage 9 kV / 12 kV
- Maximum output current 200 mA
- Maximum wire length 20 km
- Consumption 3.4 W
- Power: AC Adapter · 12 V Battery · Solar Compatible
Where it fits
- Livestock fencing
- Pasture boundaries
- Farm and crop-protection fencing
What's in the box
Package contents
- 1 ×AC Power Adapter
